6420302-1 Standby Attitude Module (SAM)

Záložní multifunkční letový přístroj MD302 (SAM) 6420302-1

Digital, 10–32 VDC, Attitude, Altitude, Airspeed, Slip, Internal battery, Black bezel

• Attitude, altitude, airspeed, slip, and vertical trend indication
• Heading via MD32 Magnetometer (optional) or aircraft system
• Five primary functions utilize modern solid-state MEMS gyro, accelerometer and pressure transducer technology
• Small 2.4” x 5.5” footprint
• Extremely lightweight — 1.6 lbs
• Self-contained, rechargeable, field-replaceable emergency battery
• Smooth, high-definition graphics
• Unique, two-screen display with wide viewing angles and a user-friendly menu structure
• Selectable orientation — horizontal and vertical
• Aircraft-specific, programmable airspeed range markings
• Configurable for static source error correction (SSEC)
• Simple user interface — one knob configures the display and provides menu control
• 10–32 VDC power input
• External, automatic and manual dimming control settings
• Software configurable lighting curves
• Field-upgradable software via standard USB port
• FAA TSO certified to C2d, C3e, C4c, C6e (incomplete), C10b, C106, C113a, C179a
• ANAC TSO certified to C2d, C3e, C4c, C10b, C106, C113a, C179a
• EASA ETSO certified to C2d, C3d (incomplete), C4c, C10b, C106, C113, C179a
• RTCA DO-178B and DO-254 Design Assurance Level (DAL) A
• RTCA DO-160 and RTCA DO-311 qualified
• Designed and built in Wichita, Kansas, USA
• Two-year or 2,000-hour warranty
